Garmin Panoptix™ PS31 Transducer
The Garmin Panoptix™ PS31 is a forward transducer with LiveVü Forward and RealVü 3-D Forward sonar modes. It provides real-time views of fish ahead of the boat and is installed by marine electronics technicians on transom or trolling motor configurations listed for PS31.
Technical Specifications
| Sonar modes | LiveVü Forward; RealVü 3-D Forward |
|---|---|
| Frequency | 417 kHz |
| Transmit power | 144 W |
| Weight | 1.8 lb (816.5 g) |
| Dimensions | 6.7 x 1.7 x 3.6 in (170.2 x 43.2 x 91.4 mm) |
| View range cited | Up to 91 m (300 ft) beneath the boat |
Compatibility & Applications
- Mounts as a forward scanning transom-mount transducer for PS31 installations.
- Mounts on trolling motor or transom configurations listed for PS31.
- Provides LiveVü Forward views of fish ahead of the boat in real time.
- Provides RealVü 3-D Forward imaging for forward-looking sonar applications.
- Fits saltwater and freshwater boat installations according to retailer application data.
- Mounts to a boat transom using a stainless steel mount.
For a transom installation, the 6.7 in body and 1.8 lb weight define mounting clearance, while the published feature set includes both LiveVü Forward and RealVü 3-D Forward imaging.
