VHF 115 Marine Radio

SKU: 010-02096-00 MFG#: 010-02096-00 UPC: 753759210748

The VHF 115 Marine Radio includes a built-in GPS & allows you to stay in contact with the shore & other boats with ease via the Garmin the NMEA 2000 network.

$449.99

Out of stock

Out of stock

Compare
Add to wishlist
19 People watching this product now!

Payment Methods:

VHF 115 Marine Radio

The VHF 115 Marine Radio is a VHF radio featuring built-in GPS, facilitating communication with shore stations and other vessels through the Garmin NMEA 2000 network. This unit is designed for installation on vessels such as powerboats and sailboats, ensuring reliable connectivity in marine environments.

Compatibility & Applications

  • Fits on boats up to 40 ft, including sailboats and powerboats.
  • Pairs with NMEA 2000 compatible devices for integrated navigation.
  • Mounts in standard dash openings for easy access.
  • Replaces older VHF models, such as the VHF 100 and VHF 110.
  • Integrates with multifunction displays for enhanced functionality.
  • Wires to 12V DC systems for power supply.
  • Includes mounting bracket for straightforward installation.

The unit serves as a reliable communication tool in marine settings, with GPS functionality improving safety and navigation. It acts as a drop-in replacement for older VHF radios, simplifying upgrades without extensive modifications.

Technical Specifications

Weight 2.74 lbs
Dimensions (L × W × H) 3.40 × 6.70 × 5.80 in
Weight2.74 lbs
Dimensions3.4 × 6.7 × 5.8 in
Unit size85 x 170 x 146 mm (3.4″ x 6.7″ x 5.8″)
Operating voltage10.8 – 15.6 VDC
Water ratingIPX7
Display Typemonochrome FSTN LCD
RegionAll U.S., Canadian and International marine channels
VHF frequency range Tx156.025–162.025 MHz
VHF frequency range Rx156.050 MHz to 163.275 MHz (including WX channels)
VHF transmit power (max)25 W, 1 W (high, low)
Transmitter frequency tolerance+/0.5 kHz
Adjacent channel power70 dB
Spurious emissions–80 dBc (at 25 W)/0.25uW
Sensitivity (12 dB SINAD)-118 dBm (-11 dBu/0.28 uV)
Adjacent channel selectivity70 dB
Spurious response70 dB
VHF intermodulation68 dB
Max antenna gain9 dBi
ClassClass D
Sensitivity (1% BER)-113 dBm
Intermodulation68 dB
ConstellationsGPS, GLONASS
Differential supportWAAS, EGNOS
Navigation rate1 Hz
Max speaker output power1 W
Max external speaker output power4 W at 4 Ω
Typical current draw at 12 Vdc600 mA, 6 A max
Compass-safe distance27″ (70 cm)
External GNSS antenna connectorBNC
Ant connectorSO-239 (50 Ω)
Frequency Range156.000 to 163.425 MHz
Power Output25 W
GPS Accuracy5 m
Dimensions6.3 x 6.1 x 2.5 in (160 x 155 x 63 mm)
Weight2.2 lbs (1 kg)
Operating Temperature-4 to 158 °F (-20 to 70 °C)
IP RatingIPX7
Connector TypeNMEA 2000
CertificationsUSCG, CE
Included AccessoriesMounting bracket, power cable, user manual
Warranty2 years
FinishBlack plastic housing

Description

VHF 115 Marine Radio

The VHF 115 Marine Radio is a VHF radio featuring built-in GPS, facilitating communication with shore stations and other vessels through the Garmin NMEA 2000 network. This unit is designed for installation on vessels such as powerboats and sailboats, ensuring reliable connectivity in marine environments.

Compatibility & Applications

  • Fits on boats up to 40 ft, including sailboats and powerboats.
  • Pairs with NMEA 2000 compatible devices for integrated navigation.
  • Mounts in standard dash openings for easy access.
  • Replaces older VHF models, such as the VHF 100 and VHF 110.
  • Integrates with multifunction displays for enhanced functionality.
  • Wires to 12V DC systems for power supply.
  • Includes mounting bracket for straightforward installation.

The unit serves as a reliable communication tool in marine settings, with GPS functionality improving safety and navigation. It acts as a drop-in replacement for older VHF radios, simplifying upgrades without extensive modifications.

Technical Specifications

Weight 2.74 lbs
Dimensions (L × W × H) 3.40 × 6.70 × 5.80 in

Specification

Overview

Weight2.74 lbs
Dimensions3.4 × 6.7 × 5.8 in
Unit size85 x 170 x 146 mm (3.4″ x 6.7″ x 5.8″)
Operating voltage10.8 – 15.6 VDC
Water ratingIPX7
Display Typemonochrome FSTN LCD
RegionAll U.S., Canadian and International marine channels
VHF frequency range Tx156.025–162.025 MHz
VHF frequency range Rx156.050 MHz to 163.275 MHz (including WX channels)
VHF transmit power (max)25 W, 1 W (high, low)
Transmitter frequency tolerance+/0.5 kHz
Adjacent channel power70 dB
Spurious emissions–80 dBc (at 25 W)/0.25uW
Sensitivity (12 dB SINAD)-118 dBm (-11 dBu/0.28 uV)
Adjacent channel selectivity70 dB
Spurious response70 dB
VHF intermodulation68 dB
Max antenna gain9 dBi
ClassClass D
Sensitivity (1% BER)-113 dBm
Intermodulation68 dB
ConstellationsGPS, GLONASS
Differential supportWAAS, EGNOS
Navigation rate1 Hz
Max speaker output power1 W
Max external speaker output power4 W at 4 Ω
Typical current draw at 12 Vdc600 mA, 6 A max
Compass-safe distance27″ (70 cm)
External GNSS antenna connectorBNC
Ant connectorSO-239 (50 Ω)
Frequency Range156.000 to 163.425 MHz
Power Output25 W
GPS Accuracy5 m
Dimensions6.3 x 6.1 x 2.5 in (160 x 155 x 63 mm)
Weight2.2 lbs (1 kg)
Operating Temperature-4 to 158 °F (-20 to 70 °C)
IP RatingIPX7
Connector TypeNMEA 2000
CertificationsUSCG, CE
Included AccessoriesMounting bracket, power cable, user manual
Warranty2 years
FinishBlack plastic housing
