VHF 215 Garmin AIS™ Marine Radio

SKU: 010-02098-00

The VHF 215 Garmin AIS™ Marine Radio displays AIS on the chartplotter, to enhance communication, situational awareness and avoid collisions on the water.

$749.99

Out of stock

Out of stock

Compare
Add to wishlist
20 People watching this product now!

Payment Methods:

VHF 215 Garmin AIS™ Marine Radio

The VHF 215 Garmin AIS™ Marine Radio is a VHF radio with Automatic Identification System (AIS) capabilities, operating within a frequency range of 156.025 – 162.025 MHz. It integrates with Garmin chartplotters to display real-time AIS data, thereby enhancing maritime communication and safety.

Compatibility & Applications

  • Pairs with Garmin chartplotters for integrated AIS data display.
  • Mounts in standard VHF radio locations on vessels up to 40 ft.
  • Wires to 12V DC power systems commonly found in marine applications.
  • Replaces older VHF models with AIS capabilities, such as Standard Horizon GX2200.
  • Integrates with NMEA 2000 networks for enhanced data sharing and communication.
  • Fits in a variety of mounting brackets designed for marine radios.

The unit enhances maritime safety by providing real-time AIS information directly on compatible chartplotters. Its IPX7 rating ensures protection against water exposure, making it reliable in harsh marine environments. Ideal for installation on center console boats, it offers superior integration capabilities compared to generic VHF radios.

Technical Specifications

Weight 2.68 lbs
Dimensions (L × W × H) 3.86 × 7.76 × 5.78 in
Weight2.68 lbs
Dimensions3.86 × 7.76 × 5.78 in
Unit size98 x 197 x 149 mm (3.9″ x 7.8″ x 5.8″)
Operating voltage10.8 – 15.6 VDC
Water ratingIPX7
Display Typemonochrome FSTN LCD
Operating temperature–15° to 55° C (5° to 131° F)
RegionAll U.S., Canadian and International marine channels; NOAA weather channels
VHF frequency range Tx156.025–162.025 MHz
VHF frequency range Rx156.050 MHz to 163.275 MHz (including WX channels)
VHF transmit power (max)25 W, 1 W (high, low)
Transmitter frequency tolerance+/0.5 kHz
Adjacent channel power70 dB
Spurious emissions–80 dBc (at 25 W) / 0.25uW
Sensitivity (12 dB SINAD)-118 dBm (-11 dBu/0.28 uV)
Adjacent channel selectivity70 dB
Spurious response70 dB
VHF intermodulation68 dB
Max antenna gain9 dBi
ClassClass D
Sensitivity (1% BER)-113 dBm
Intermodulation68 dB
Remote station supportGHS 11 (x1)
AIS Sensitivity (20% PER)-107 dBm
ConstellationsGPS, GLONASS
Differential supportWAAS, EGNOS
Navigation rate1 Hz
Max speaker output power1 W
Max external speaker output power4 W at 4 Ω
Max hailer loudspeaker output power20 W at 4 Ω
Typical current draw at 12 Vdc600 mA, 6 A max
Compass-safe distance75 cm (29.5″)
External GNSS antenna connectorBNC
Ant connectorSO-239 (50 Ω)
Frequency range156.025 – 162.025 MHz
Power output25 W
Dimensions6.1 x 5.6 x 3.4 in (155 x 142 x 86 mm)
Weight2.4 lbs (1.1 kg)
Operating temperature range-20 to 60 °C (-4 to 140 °F)
IP ratingIPX7 waterproof
Included accessoriesMicrophone, mounting kit, power cable
Country of originChina
Warranty2 years
Connector type12V DC

Description

VHF 215 Garmin AIS™ Marine Radio

The VHF 215 Garmin AIS™ Marine Radio is a VHF radio with Automatic Identification System (AIS) capabilities, operating within a frequency range of 156.025 – 162.025 MHz. It integrates with Garmin chartplotters to display real-time AIS data, thereby enhancing maritime communication and safety.

Compatibility & Applications

  • Pairs with Garmin chartplotters for integrated AIS data display.
  • Mounts in standard VHF radio locations on vessels up to 40 ft.
  • Wires to 12V DC power systems commonly found in marine applications.
  • Replaces older VHF models with AIS capabilities, such as Standard Horizon GX2200.
  • Integrates with NMEA 2000 networks for enhanced data sharing and communication.
  • Fits in a variety of mounting brackets designed for marine radios.

The unit enhances maritime safety by providing real-time AIS information directly on compatible chartplotters. Its IPX7 rating ensures protection against water exposure, making it reliable in harsh marine environments. Ideal for installation on center console boats, it offers superior integration capabilities compared to generic VHF radios.

Technical Specifications

Weight 2.68 lbs
Dimensions (L × W × H) 3.86 × 7.76 × 5.78 in

Specification

Overview

Weight2.68 lbs
Dimensions3.86 × 7.76 × 5.78 in
Unit size98 x 197 x 149 mm (3.9″ x 7.8″ x 5.8″)
Operating voltage10.8 – 15.6 VDC
Water ratingIPX7
Display Typemonochrome FSTN LCD
Operating temperature–15° to 55° C (5° to 131° F)
RegionAll U.S., Canadian and International marine channels; NOAA weather channels
VHF frequency range Tx156.025–162.025 MHz
VHF frequency range Rx156.050 MHz to 163.275 MHz (including WX channels)
VHF transmit power (max)25 W, 1 W (high, low)
Transmitter frequency tolerance+/0.5 kHz
Adjacent channel power70 dB
Spurious emissions–80 dBc (at 25 W) / 0.25uW
Sensitivity (12 dB SINAD)-118 dBm (-11 dBu/0.28 uV)
Adjacent channel selectivity70 dB
Spurious response70 dB
VHF intermodulation68 dB
Max antenna gain9 dBi
ClassClass D
Sensitivity (1% BER)-113 dBm
Intermodulation68 dB
Remote station supportGHS 11 (x1)
AIS Sensitivity (20% PER)-107 dBm
ConstellationsGPS, GLONASS
Differential supportWAAS, EGNOS
Navigation rate1 Hz
Max speaker output power1 W
Max external speaker output power4 W at 4 Ω
Max hailer loudspeaker output power20 W at 4 Ω
Typical current draw at 12 Vdc600 mA, 6 A max
Compass-safe distance75 cm (29.5″)
External GNSS antenna connectorBNC
Ant connectorSO-239 (50 Ω)
Frequency range156.025 – 162.025 MHz
Power output25 W
Dimensions6.1 x 5.6 x 3.4 in (155 x 142 x 86 mm)
Weight2.4 lbs (1.1 kg)
Operating temperature range-20 to 60 °C (-4 to 140 °F)
IP ratingIPX7 waterproof
Included accessoriesMicrophone, mounting kit, power cable
Country of originChina
Warranty2 years
Connector type12V DC
