BLUE SEA Circuit Breaker Push Button QC 10A Fuse & Breaker
The BLUE SEA Circuit Breaker Push Button QC 10A is a push-button reset-only circuit breaker rated at 10 A. It provides circuit protection in marine electrical panels for installers building DC branch circuits, fuse-and-breaker panels, or master-switch assemblies.
Technical Specifications
| Current rating | 10 A |
|---|---|
| Maximum voltage | 32 VDC |
| Mounting | Panel mount, 3/8-27 UNS |
| Breaker type | Thermal trip, manual push-button reset only |
| Poles | 1 |
| Weight | 0.06 lb (27.2 g) |
| Dimensions | 1 x 3 x 4 in (25.4 x 76.2 x 101.6 mm) |
Compatibility & Applications
- Mounts in electrical panels using a 3/8-27 UNS panel-mount format.
- Wires into DC circuits with a listed maximum voltage of 32 VDC.
- Fits installations aboard gasoline powered boats, according to the cited retailer listing.
- Pairs with circuits requiring a 10 A thermal-trip breaker.
- Wires with quick-connect breaker connections identified by the QC product name.
In a boat DC distribution panel, the unit protects a 10 A circuit and resets manually from the panel face. Its documented 3/8-27 UNS panel mount gives a defined threaded mounting specification.
