Garmin AIS™ 800 Blackbox Transceiver
$1,099.99
The Garmin AIS™ 800 Blackbox Transceiver allows you to receive AIS target data as well as transmit your own vessel information to other AIS receivers in your area.
Did you like this product? Add to favorites now and follow the product.
We are experts and sell products with a 15% discount with installation. Contact us via any method you prefer, such as WhatsApp, email, or SMS, or ask the team to sell you the equipment. Start Live Chat
Description
The Garmin AIS™ 800 Blackbox Transceiver allows you to receive AIS target data as well as transmit your own vessel information to other AIS receivers in your area.
Additional information
| Unit size | 175 x 142 x 55 mm (6.9" x 5.6" x 2.1") |
|---|---|
| Weight | 0.9 lb (414 g) |
| Operating voltage | 9.6 – 31.2 VDC |
| Water rating | IPX7 |
| Operating temperature | -15°C to 55°C (5°F to 131°F ) |
| Splitter connector | TNC |
| Spurious response | 70 dB |
| Max antenna gain | 6 dBi |
| Class | SOTDMA Class B; CSTDMA Class B (optional) |
| Frequency range | 156.025 – 162.025 MHz |
| AIS Sensitivity (20% PER) | -110 dBm |
| Adjacent channel selectivity | 70 dB |
| Intermodulation | 65 dB |
| Splitter insertion loss | RX 0 dB, TX -0.9 dB |
| Constellations | GPS, GLONASS, Galilleo |
| Differential support | SBAS, AIS Msg 17 |
| Navigation rate | 1 Hz |
| Typical current draw at 12 Vdc | 400 mA |
| Compass-safe distance | 40 cm (15.8") |
| Power output | 5 W |
| NMEA 0183 detail | 1 NMEA 0183 port, AIS & GPS sentences, 4800/38400 baud |
| External GNSS antenna connector | BNC |
| Ant connector | SO-239 (50 Ω) |
